| Maximum print width | 6600mm |
|---|---|
| Maximum panel width | 6600mm |
| Maximum roll media width | 6650mm |
| Maximum media thickness | 50mm |
| Printing Speed | Uni-dir SQM/H (no feather) | Bi-dir SQM/H (no feather) |
|---|---|---|
| 2pass | 465m2/h | 700m2/h |
| 3pass | 308m2/h | 521m2/h |
| 4pass | 231m2/h | 415m2/h |
| 6pass | 153m2/h | 295m2/h |
| 8pass | 117m2/h | 229m2/h |
| Mode of Equipmen | HY-6600 | Printing system | Dlican developed hybrid UV printer |
|---|---|---|---|
| Dpi-Resolution | up to 1440dpi | standard colors | C、M、Y、K |
| Opsitonal Soluiton | Ic、 Im. ly、 lk, R、 G, B、 0. W. V | Curing method | UV-Led curing system |
| File Format | PDF、TIFF(RGB&CMYK)、 BMP、 EPS、JPEG | RIP Software | Caldera、 PrintFactory、 Onyx |
| Power Requirment | AC220V(+10%); 50HZ; P:10000W | Printer Dimension | 9670mm*2150mm*1900mm |
| Printer Weight | 8500KG | Printhead | km1024i |
